Ajax Hub 2 Plus Jeweller Security Control Panel with Photo Verification (44527.40.WH3)

Hub 2 Plus Jeweller is an Ajax security system control panel supporting photo verification and compatible with all Ajax wireless devices of the Jeweller product line. It connects via Ethernet, Wi-Fi and two SIM cards (2G/3G/4G), runs up to 200 devices and 200 users, and delivers MotionCam alarm photos in 9 seconds. A backup battery provides up to 15 hours of operation in case of a blackout.

Ideal applications

  • Large premises such as business centres, factories and multi-story villas with outbuildings
  • Security systems with photo verification of alarms (MotionCam detectors)
  • Sites divided into up to 25 security groups with staff access control
  • Connection to alarm monitoring companies (CMS)

Key Features

  • 4 communication channels: Ethernet, Wi-Fi, and two SIM cards (2G/3G/4G)
  • Detectors with photo verification support
  • Up to 200 devices and up to 200 users
  • Up to 100 cameras or DVRs
  • Up to 25 security groups and up to 64 scenarios
  • Up to 5 range extenders
  • Jeweller (alarms, up to 2,000 m) and Wings (photos, up to 1,700 m) radio protocols
  • 0.3 s alarm delivery, 9 s first photo delivery
  • Backup battery: up to 15 hours of operation during a blackout
  • Remote control and setup via the app; connecting via QR code

Compliance

Compliance with standards
EN 50131 (Grade 2), PD 6662:2017

Connected Devices & Features

Connected devices
Up to 200 wireless devices, including up to 5 range extenders and up to 10 sirens
Users
200
Cameras or DVRs
100
Automation scenarios
64
Security groups
25

Communication with Ajax Devices

Technologies
Jeweller communication technology; Wings communication technology
Frequency bands
866.0–866.5 MHz, 868.0–868.6 MHz, 868.7–869.2 MHz, 905.0–926.5 MHz, 915.85–926.5 MHz, 921.0–922.0 MHz (depends on the region of sales)
Maximum effective radiated power (ERP)
≤25 mW
Jeweller communication range
Up to 2,000 m (in an open space)
Wings communication range
Up to 1,700 m (in an open space)

External Communication Channels

Ethernet
8P8C slot, up to 100 Mb/s
Wi-Fi
802.11 b/g/n
Cellular network
2 slots for micro-SIMs; 2G (GSM900/DCS1800 (B3/B8)), 3G (WCDMA 850/900/2100 (B1/B5/B8)), 4G/LTE (FDD B1/B3/B5/B7/B8/B20)

Connection to CMS

Protocols
SurGard (Contact ID), SIA (DC-09), ADEMCO 685, other proprietary protocols

Power Supply

Main power supply
100–240 V~, 50/60 Hz
Backup power supply
Li-Ion battery with 2 A⋅h capacity

Installation

Operating temperature range
From -10°С to +40°С
Operating humidity
Up to 75%
Protection class
IP20

Enclosure

Colour
White, black
Dimensions
163 × 163 × 36 mm
Weight
351 g
Tampering alarm
Yes

Complete Set

Package contents
Hub 2 Plus Jeweller; Power cable; Ethernet cable; SIM card (depends on the region of sale); Installation kit; Quick Start Guide

Notes

Note
The hub cannot be connected to another hub. uartBridge or ocBridge Plus cannot be connected to the Ajax hubs.
