Technical Specifications

Camera

Image Sensor
8 MP CMOS, 1/2.7" Sensor
Lens
2.8 mm Fixed Lens
Maximum Aperture
f/1.6
Lens Type
Fixed Iris
Horizontal Viewing Angle
110°
Vertical Viewing Angle
56°
Diagonal Viewing Angle
126°
Night Vision Distance
Up to 50 m (164 ft) with IR & White LEDs
Lighting Control
Automatic Intelligent Hybrid Illumination

Video

Maximum Resolution
3840 × 2160 (8 MP)
Supported Resolutions
8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2 MP, 0.6 MP
Frame Rate
Up to 20 FPS
Image Rotation
0°, 180°
Video Compression
H.265, H.264
Dynamic Range
True WDR

Storage & Audio

Local Storage
microSD Card (Up to 256 GB, Class V30 or Faster)
Network Storage
Ajax NVR
Microphone
Built-in
Audio Codecs
G711-ULAW, G711-ALAW, G726, G722

AI Analytics

Motion Detection
Software-Based Motion Detection
AI Object Detection
People, Pets, Vehicles

Network & Integration

Ethernet Port
1 × RJ-45 (10/100 Mbps)
Protocols
HTTP, HTTPS, TCP/IP, IPv4, IPv6, SNMP, RTSP, UDP, DHCP, DNS, DDNS
ONVIF Support
Profile S & Profile T
Video Protocol
JetSparrow Encrypted P2P

Security Features

Alarm Verification
Ajax Event-Based Video Recording
Encryption
mTLS
Authentication
Ajax Cloud
Firmware Protection
Secure Boot & OTA Signature Verification

Power

PoE Standard
IEEE 802.3af / 802.3at
Alternative Power
12 V DC ±20%, 1 A

Physical

Dimensions
103 × 98 × 98 mm
Weight
475 g
Operating Temperature
-30°C to +60°C
Operating Humidity
Up to 90%
Protection Rating
IP65
Available Colors
White, Black
