Hikvision DS-2CD6D52G0-IHS Dual-Directional 5MP PanoVu IP Camera PoE IR IK10 IP67
Hikvision DS-2CD6D52G0-IHS Dual-Directional 5MP PanoVu IP Camera PoE IR IK10 IP67
Available in stock (18)
products.product.pickup_availabilities
Description
Description
Hikvision DS-2CD6D52G0-IHS Dual-Directional PanoVu Camera
If you’ve ever felt like one camera never covers enough—or adding more cameras only creates more cost, more wiring, and more complexity—the DS-2CD6D52G0-IHS was built to solve that problem. Its dual-directional PanoVu design lets you monitor two areas at once, helping you protect more space with fewer devices. You get sharp 5 MP video, intelligent alerts, strong low-light performance, and weather-ready durability in one compact unit. Instead of constantly wondering what you missed, this camera helps you feel in control of the areas that matter most. That means smarter coverage, easier installation planning, and greater confidence every day.
Why Buyers Choose This Model
What This Helps You Avoid
Many buyers start with a standard camera and later realize it didn’t cover enough. Then they add another camera, more cabling, more setup time, and still deal with awkward blind spots. If something important happens, poor lighting or low detail can turn footage into frustration instead of answers.
The DS-2CD6D52G0-IHS helps break that cycle. With dual-direction coverage, smart alerts, strong image quality, and dependable outdoor protection, it gives you a more complete solution from the start. Instead of reacting after problems happen, you’re putting yourself in a stronger position before they do.
Product Support & Shipping Details
Product Support & Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
For Support you’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Downloads
Product Manuals, data sheets.
Downloads
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
DS-1280ZJ-DE7 Junction Box
Technical Specifications
Hikvision DS-2CD6D52G0-IHS Dual-Directional PanoVu Camera
The Hikvision DS-2CD6D52G0-IHS is a dual-directional PanoVu network camera built for users who need to watch two directions at once without adding more cameras, more cabling, or more setup headaches. Its dual-lens design helps you cover entrances, hallways, corners, and building perimeters more efficiently, while 5 MP imaging, 120 dB WDR, and flexible angle adjustment make it easier to capture usable video in real-world lighting. You also get built-in analytics, local storage support up to 256 GB, IP67 weather resistance, and IK10 vandal resistance for dependable indoor or outdoor deployment.
In practical terms, this matters because you can reduce blind spots, simplify installation planning, and get clearer evidence when something happens. Instead of piecing coverage together with multiple standard cameras, this model is designed to give you broader directional awareness from a single device.
Ideal Applications / Common Uses
The datasheet does not list vertical-specific use cases like retail, warehouse, office, or school by name. What it does show is a dual-directional design, flexible pan/tilt/rotate adjustment, perimeter analytics, IP67 weather resistance, IK10 vandal resistance, and a note that this model has no specific anti-corrosion protection, meaning it is intended for environments where special anti-corrosion protection is not required.
- Building corners and exterior walls where two viewing directions are needed
- Hallways, intersections, and corridor monitoring
- Entrances, exits, and gate approaches
- Perimeter zones where line crossing or intrusion alerts are useful
- General indoor/outdoor deployments in standard environments without special anti-corrosion requirements
Key Features
- Dual lens design — monitor two directions with one camera, which helps reduce blind spots and hardware count.
- 2560 × 1920 resolution at up to 30 fps — gives you sharper video for reviewing events with more confidence.
- 120 dB WDR — helps keep details visible when bright backlight would normally wash out the image.
- Flexible angle adjustment — makes placement easier when you need to fine-tune coverage around corners or walkways.
- H.265/H.265+/H.264/H.264+ — helps manage bandwidth and storage more efficiently.
- Built-in micro SD storage up to 256 GB — adds local recording flexibility if network recording is interrupted.
- IP67 and IK10 — built for outdoor exposure and better resistance against vandalism.
- Built-in analytics — supports proactive alerts for events like intrusion, line crossing, and scene change.
Camera
Lens
DORI
Illuminator
Video
Audio (-S)
Network
Web Browser
Interface
Smart Feature-Set
General
Approval / Protection
Accessories
Downloads
Frequently Asked Questions
The biggest difference is its dual-directional PanoVu design. This camera uses a dual-lens setup, which means it can monitor two directions at once instead of covering only one view like a standard fixed camera. That matters when you want to watch hallways, corners, entrances, or exterior walls without installing multiple separate cameras. The datasheet also shows flexible angle adjustment with P: -90 to 90°, T: 0 to 60° for 2.8 mm or 0 to 70° for 4/6 mm, and R: 0 to 355°, giving you more control over how each view is positioned.
The DS-2CD6D52G0-IHS supports a maximum resolution of 2560 × 1920, and the main stream can run at up to 30 fps at 60 Hz. In practical terms, that gives you 5 MP-class imaging that is designed to preserve more scene detail than lower-resolution cameras. The datasheet also lists 120 dB wide dynamic range, which helps the camera handle scenes with strong backlight more effectively. That is especially helpful near doorways, loading areas, or windows where bright and dark zones appear in the same scene.
Yes, the datasheet shows low-light performance for both color and black-and-white operation, plus IR support. Minimum illumination is listed as Color: 0.009 Lux @ (F1.6, AGC ON) and B/W: 0.0018 Lux @ (F1.6, AGC ON), with 0 Lux using IR. It also includes an IR range of up to 10 meters, 850 nm wavelength, and Smart Supplement Light. Together, those specs indicate the camera is built to keep producing usable images in darker environments rather than becoming ineffective once ambient light drops.
It supports both 12 VDC power and PoE, specifically 802.3af. That gives you more installation flexibility because you can power the camera using a compatible network switch or injector, or use a traditional 12 VDC power source if that better fits the jobsite. The datasheet lists maximum power consumption at 11 W, whether powered by 12VDC or PoE within the supported voltage range. For many installers, PoE matters because it simplifies cabling and reduces the number of separate power components needed at the camera location.
Yes. The datasheet states that the camera has a built-in micro SD/SDHC/SDXC card slot and supports cards up to 256 GB. That gives you an onboard storage option for local recording, which can be useful for standalone deployments or as an added layer of recording redundancy. It also supports network storage to NAS using NFS and SMB/CIFS, so you are not limited to just one storage method. This flexibility is helpful when you want local backup at the camera and centralized storage elsewhere on the network.
Yes, but the exact audio configuration depends on the model version. The datasheet says that the version without “-S” has 2 built-in microphones, while the “-S” version has 2 built-in microphones plus 1 line in and 1 line out. It also supports stereo audio, noise filtering, and multiple audio compression formats including G.711, G.722.1, G.726, MP2L2, and PCM. Since your model is DS-2CD6D52G0-IHS, it is the “-S” version, so it includes the expanded audio interface options listed in the datasheet.
The datasheet lists several built-in smart events, including line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, and audio exception detection on Channel 1 only. It also supports basic events such as motion detection, video tampering alarm, and exception alerts like network disconnected, IP address conflict, illegal login, HDD full, and HDD error. One important note from the datasheet is that rotate and perimeter protection events cannot be enabled at the same time. That matters during setup because it affects how you balance image orientation with event-based detection functions.
Yes. The datasheet lists Hik-Connect and iVMS-4200 as supported clients, which means it is designed for remote access and management through Hikvision’s ecosystem. It also supports ONVIF Profile S, Profile G, and Profile T, along with ISAPI and SDK, which can help with broader compatibility in network video environments. For browser access, the datasheet notes plug-in free live view on Chrome 57.0+, Firefox 52.0+, and Safari 11+, plus local service support for Chrome 41.0+ and Firefox 30.0+. That gives you several ways to view and manage the camera depending on your setup preference.
For general outdoor use, yes. The camera is rated IP67 for ingress protection and IK10 for vandal resistance, and the datasheet also lists a built-in heater plus startup and operating conditions down to -40° and up to 60° with humidity up to 95% non-condensing. That makes it a strong fit for demanding weather conditions and exposed mounting locations. The important limitation is that Hikvision also states this model has “NO SPECIFIC PROTECTION” for special anti-corrosion environments, so it is not the right choice for places that require professional anti-corrosion protection such as certain coastlines, docks, or chemical plants.
The datasheet shows that the DS-2CD6D52G0-IHS is available in 2.8 mm, 4 mm, and 6 mm versions. The 2.8 mm lens offers the widest horizontal field of view at 97°, while the 4 mm version provides 79°, and the 6 mm version provides 49°, so buyers can choose between wider scene coverage or a tighter, longer-reaching view. Hikvision also lists optional compatibility with WMS and WML, plus the DS-1280ZJ-DE7 Junction Box and PC-6D Adapter Cap as accessories. This is useful when planning mounting hardware and cable management before installation rather than discovering later that you need extra parts.
