Hikvision DS-7732NXI-I4/S 32CH no-PoE 4SATA AcuSense 4K NVR 4-ch Deep-Learning

Data sheet PDF

Product Description

32ch 1U AcuSense 4K NVR

• H.265+/H.265/H.264+/H.264 video formats
• Intelligent analytics based on deep learning algorithm
• Up to 4ch perimeter protection
• Up to 4ch facial recognition for video stream
• Up to 8ch facial recognition for face picture
• Up to 32ch IP camera inputs
• Up to 32ch 1080p decoding capability

Intelligent Analytics

Facial Recognition

Motion Detection 2.0

Perimeter Protection

ANPR

Video And Audio

Decoding

Network

Auxiliary Interface

General

Certification

• Intelligent Analytics
• AI By Device
• AI By Camera
• Engine
• Facial Recognition
• Facial Detection And AnalyticsFace picture comparison, human face capture, face picture search
• Face Attributes
• Face Picture LibraryUp to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ? 512 KB, total capacity ? 150 MB)
• Face Picture Comparison (Captured From Camera)4ch face picture comparison alarm
• Facial Detection And Analytics Performance1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
• Motion Detection 2.0
• By Device16ch
• By Camera
• Perimeter Protection
• By Device

  Up to 4ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;

  Up to 12 rules in total;Up to 4ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;

  Up to 12 rules in total;Up to 4ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;

  Up to 12 rules in total

• By Camera
• ANPR
• By Camera
• Vehicle Attributes
• Plate Attributes
• Video And Audio
• IP Video Input

  16ch

  Up to 12 MP resolution

  *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.

• Incoming Bandwidth160 Mbps
• Outgoing Bandwidth256 Mbps
• HDMI 1 Output4K (3840 ? 2160)/60Hz, 4K (3840 ? 2160)/30Hz, 2K (2560 ? 1440)/60Hz, 1920 ? 1080/60Hz, 1600 ? 1200/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz, HDMI1/VGA simultaneous output
• HDMI 2 Output1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz, HDMI2/VGA independent output
• VGA Output

  1-ch, 1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz,

  HDMI1/VGA simultaneous output

• Video Output Mode
• CVBS Output1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 ? 576, NTSC: 704 ? 480
• Audio Output1-ch, RCA (Linear, 1 K?)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 K?)
• Decoding
• Decoding FormatH.265+/H.265/H.264+/H.264/MPEG4
• Recording Resolution

  32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF

  *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled.

• Synchronous Playback16ch
• Live View Window Division1/2/4/6/8/9/16
• Aux Port Window Division1/2/4/6/8/9/16
• Decoding Capability16ch @ 1080p (30 fps)
• Dual-Stream RecordingSupport
• Stream TypeVideo, Video & Audio
• Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/MP2L2
• Network
• Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
• Remote Connection128
• Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP?, HTTP, HTTPS
• API
• Compatible Browser
• Auxiliary Interface
• Serial InterfaceRS-485 (half-duplex), RS-232, Keyboard
• SATA4 SATA interfaces supporting hot-plug
• CapacityUp to 10 TB capacity for each disk
• ESATA1 eSATA interface
• Alarm In/Out16/4
• USB InterfaceFront panel: 2 ? USB 2.0; Rear panel: 1 ? USB 3.0
• Ctrl 12V
• DC 12V
• General
• GUI Language
• Power Supply100 to 240 VAC, 50 to 60 Hz
• Consumption? 30 W (without HDD)
• Working Temperature-10 ?C to 55 ?C (14 ?F to 131 ?F)
• Working Humidity10% to 90%
• Chassis19-inch rack-mounted 1.5U chassis
• Dimension (W ? D ? H)445 ? 400 ?75 mm ( 17.5"? 15.7" ? 3.0")
• Weight? 5.6 kg (12.3 lb)
• Certification
• Obtained Certification
• CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
•
