Uniview UNV 8 Channel 8PoE & 4K Ultra 265 Network Video Recorder UN-NVR301-08S3-P8
? Max Recording Resolution: 8MP
? Channels: 8CH
? Built-in POE : 8 Port PoE
? LAN Ports:
? SATA: 1X SATA PORT
? Video Outputs:
? NDAA Compliant: Yes
? VCA Features:
? Hardware Features:
Product Support & Shipping Details
Product Support & Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
For Support you’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Technical Specifications
Data sheet PDF
Product Description
Uniview UNV 8 Channel 8PoE & 4K Ultra 265 Network Video Recorder UN-NVR301-08X-P8
? Max Recording Resolution: 8MP
? Channels: 8CH
? Built-in POE : 8 Port PoE
? LAN Ports:
? SATA: 1X SATA PORT
? Video Outputs:
? NDAA Compliant: Yes
? VCA Features:
? Hardware Features:
Specifications
Uniview UNV 8 Channel 8PoE & 4K Ultra 265 Network Video Recorder Features
Support Ultra 265/H.265/H.264 video formats
8-channel input
Plug & Play with 8 independent PoE network interfaces
Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
Support 1-ch HDMI, 1-ch VGA, HDMI at up 4K(3840?2160) resolution
HDMI and VGA simultaneous output
Up to 8MP resolution recording
1 SATA HDD up to 10 TB
Support cloud upgradeUniview UNV 8 Channel 8PoE & 4K Ultra 265 Network Video Recorder Smart Features
VCA Detection: Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
VCA Search: Face search, Behavior search
Statistical Analysis: People counting
Weight 4.486402 lbs
Dimensions 17.1653636 ? 3.1889781 ? 11.4566991 in
Specifications
Model UN-NVR301-08X-P8
Video/Audio Input
IP Video Input 8-ch
Two-way Audio Input 1-ch, RCA
Network
Incoming Bandwidth 64Mbps
Outgoing Bandwidth 64Mbps
Remote Users 128
Protocols P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA Output
HDMI:
3840x2160/30Hz,1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz,
1280x720/60Hz, 1024x768/60Hz
VGA:
1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Recording Resolution 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Synchronous Playback 8-ch
Corridor Mode Screen 3/4/5/7/9
DATASHEET
Decoding
Decoding format Ultra 265/H.265/H.264
Liveview/Playback 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability 2 x 4k@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30,8 x 1080p@30, 16 x 720p@30
Hard Disk
SATA 1 SATA interface
Capacity up to 10TB for each disk
Smart
VCA Detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change
detection, Auto tracking
VCA Search Face search, Behavior search
Statistical Analysis People counting
External Interface
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface Rear panel: 1 x USB2.0,1 x USB3.0
PoE
Interface 8 independent 100 Mbps PoE network interfaces
Max Power
Max 30W for single port
Max 108W in total (13.5W for each)
Supported Standard IEEE 802.3at, IEEE 802.3af
General
Power Supply
52V DC
Power Consumption: ?8 W (without HDD)
Working Environment -10?C ~ + 55?C (+14?F ~ +131?F), Humidity ? 90% RH (non-condensing)
Dimensions (W?D?H) 260mm ? 240mm ? 47mm (10.2"?9.4"?1.9 ")
Weight (without HDD) 1kg (2.20 lb)
