DS-3E0510P-E Hikvision 8 Port Gigabit Unmanaged POE Switch

The Hikvision DS-3E0510P-E is an 8 Port Gigabit Unmanaged PoE Switch. Highlights include layer 2 network switch designed for video data transmission, IEEE 802.3 af & at high PoE power supply Store-and-forward switching and safe and reliable using 6 kV high surge protection.

Ideal applications

  • Powering and networking IP cameras and other PoE devices
  • Home, office and small business networks

Key Features

  • Layer 2 network switch designed for video data transmission
  • 8 x 10/100/1000 Mbps ethernet port, 1 x 10/100/1000 Mbps uplink ethernet port and 1 x 10/100/1000 Mbps uplink SFP port
  • IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z network standards available
  • IEEE 802.3 af & at high PoE power supply Store-and-forward switching
  • Safe and reliable using 6 kV high surge protection
  • Plug and play ensures simplicity and convenience.

Specifications

Model
DS-3E0510P-E

General

Shell
Metal material, fan-free design
Net Weight
0.6 kg (1.32 lb)
Gross Weight
1.4 kg (3.09 lb)
Dimensions (W × H × D)
217.6 mm × 27.8 mm × 108.55 mm (8.6'' × 1.1'' × 4.3'')
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature
-40 °C to 85 °C (-40 °F to 185 °F)
Operating Humidity
5% to 95% (no condensation)
Relative Humidity
5% to 95% (no condensation)
Power Supply
48 V DC, 2.5 A
Max. Power Consumption
120 W
Power Consumption in Idle
10 W
Installation Mode
Desk-Mounted,Wall-Mounted;
Surge Protection
6 kV
Network Parameters
Ports; 8 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port
MAC Address Table
4 K
Switching Capacity
20 Gbps
Packet Forwarding Rate
14.88 Mpps
Internal Cache
1.5 Mbits
PoE Power Supply
PoE Standard; IEEE 802.3af,IEEE 802.3at
PoE Power Pin
End-span: 1/2(+), 3/6(-)
PoE Port
PoE: Ports 1 to 8
Max. Port Power
30 W
PoE Power Budget
110 W

Approval

EMC
FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32:; 2015)
Safety
UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
Chemistry
CE-RoHS (2011/65/EU)
HK-SFP-1.25G-20-1550 SFP Module
HK-SFP-1.25G-20-1310; SFP Module; HK-SFP-1.25G-1310-DF-MM; SFP Module; HK-SFP-1.25G-20-1310-DF; SFP Module
