This camera delivers an 8 MP maximum resolution of 3840 × 2160. That level of detail is designed to clearly capture faces, vehicles, and other critical details needed for identification. The high resolution also supports better digital zoom compared to lower-megapixel cameras. According to the datasheet, the camera supports multiple resolutions across its main and sub-streams for flexible deployment.

Yes, the datasheet specifies that the camera supports motion detection with alarm triggering based on specified target types, including humans and vehicles. This helps reduce false alarms caused by irrelevant motion like animals or environmental changes. The feature is part of the camera’s basic event functions. Alerts can then trigger actions such as recording, notifications, or deterrence features.

The IPC-D3683WD-RB uses a smart hybrid light system that includes both infrared (IR) and white light. The supplement light range is rated up to 30 meters, allowing for clear nighttime coverage. IR illumination uses an 850 nm wavelength, while the white light can provide visible color imaging. The smart supplement light automatically adapts based on scene conditions.

Yes, this model includes active deterrence features such as a flashing strobe light with red and blue illumination and an audible warning. The datasheet confirms that these can be triggered by events like motion detection. These deterrence functions are designed to draw attention and discourage unwanted activity. They can also be linked with alarms, recording, and notifications.

The camera includes a built-in microphone and a built-in speaker, enabling two-way audio functionality. Audio supports mono sound with sampling rates of 8 kHz or 16 kHz. Multiple audio compression formats are supported, including G.711, G.722.1, G.726, MP2L2, PCM, and AAC-LC. This allows users to listen and communicate through the camera when needed.

According to the datasheet, the camera supports H.265+, H.265, H.264+, and H.264 for the main stream. The sub-stream supports H.265, H.264, and MJPEG. These compression options are designed to balance video quality with storage and bandwidth efficiency. Bit rates are adjustable from 32 Kbps up to 16 Mbps.

Yes, the camera includes a built-in memory card slot that supports microSD, microSDHC, and microSDXC cards. The maximum supported storage capacity is up to 512 GB. This allows for local recording without requiring an external NVR in some use cases. Recording can be triggered by events or continuous recording, depending on configuration.

The camera is rated IP67 according to IEC 60529 standards, indicating strong protection against dust and water. It is designed to operate in temperatures from -30 °C to 60 °C (-22 °F to 140 °F). These specifications make it suitable for outdoor installations in a wide range of environments. The metal and plastic housing further supports durability.

The datasheet lists two power options: 12 VDC input and Power over Ethernet (PoE). PoE follows the IEEE 802.3af standard, Class 3, with a maximum power consumption of 9.5 W. Using PoE allows both power and data to be delivered through a single Ethernet cable. This can simplify installation and reduce wiring complexity.

The fixed 2.8 mm lens provides a wide horizontal field of view of 105 degrees, a vertical field of view of 55 degrees, and a diagonal field of view of 127 degrees. This wide coverage makes it suitable for monitoring entrances, parking areas, and open spaces. The lens uses a fixed iris with an F1.6 aperture. These specifications are intended to balance coverage and low-light performance.
