HIKVISION 64CH NVR DS-9664NI-I8 UP TO 12MP 64 CHANNEL 8 SATA PRO LINE
HIKVISION 64CH NVR DS-9664NI-I8 UP TO 12MP 64 CHANNEL 8 SATA PRO LINE
Out of stock
Description
Description
Hikvision DS-9600NI-I8 Series Professional NVR
When you're managing a larger surveillance system, is simply having enough camera channels really enough—or do storage capacity, reliability, playback performance, and room to grow matter just as much?
The Hikvision DS-9600NI-I8 Series is built for demanding IP video systems, with 16-, 32-, and 64-channel models, support for cameras up to 32 MP, eight SATA drive interfaces, RAID storage options, and high incoming bandwidth.
Instead of building a system that becomes a bottleneck as your surveillance needs increase, this NVR gives you the recording capacity, storage flexibility, video outputs, and network tools needed to manage a more substantial security environment from one platform.
For businesses and professional installations where recorded video matters, the DS-9600NI-I8 Series is designed to make managing large amounts of surveillance footage more practical, organized, and reliable.
Why Buyers Choose the DS-9600NI-I8 Series
A surveillance system becomes much more valuable when the recorder behind it can actually keep up with the cameras connected to it. The DS-9600NI-I8 Series combines high camera capacity, high-resolution recording, expandable storage, RAID support, and professional video management features in one NVR platform.
16, 32 or 64 IP Camera Channels — Build the System Around Your Property
Choose from 16-, 32-, or 64-channel versions depending on the size of your surveillance system. That gives you the flexibility to cover larger properties without forcing every installation into the same recorder size.
Up to 32 MP Camera Support — Preserve the Detail Your Cameras Can Capture
High-resolution cameras are only useful if the recorder can handle them. The DS-9600NI-I8 Series supports IP camera resolutions up to 32 MP, helping you build a system around higher-resolution video rather than limiting your camera choices because of the recorder.
High Decoding Capacity — Review More Video Without Sacrificing Resolution
The NVR can decode up to 1 channel at 32 MP, 2 channels at 12 MP, 4 channels at 8 MP, 8 channels at 4 MP, or 16 channels at 1080p. This gives operators practical flexibility when viewing multiple high-resolution cameras at the same time.
8 SATA Drive Bays — Build Storage Around Your Recording Needs
With eight SATA interfaces and support for up to 10 TB per disk, you have considerably more flexibility to configure storage around the number of cameras, recording resolution, and retention requirements of the installation.
RAID 0/1/5/6/10 Support — Add Another Layer of Storage Reliability
When recorded evidence matters, relying on a basic single-drive configuration may not provide the storage strategy you want. The DS-9600NI-I8 supports RAID 0, 1, 5, 6, and 10, allowing compatible multi-drive systems to be configured around different performance and redundancy requirements.
Hot-Swappable Hard Drives — Make Storage Maintenance More Practical
The eight SATA interfaces support hot-plug operation. For systems where storage maintenance needs to be handled efficiently, hot-swappable drive support makes servicing the recorder's storage configuration more convenient.
H.265+ Compression — Store More Video Using Available Drive Space More Efficiently
Storage can become one of the biggest considerations in a large camera system. Hikvision states that H.265+ can reduce storage space requirements by up to 75%, helping you use available hard-drive capacity more efficiently.
Dual-Stream Recording — Reduce Unnecessary Bandwidth Usage
Dual-stream recording helps save bandwidth, which becomes increasingly important as more cameras and users are added to the surveillance system.
Up to 320 Mbps Incoming Bandwidth — Handle Demanding Multi-Camera Systems
The DS-9616NI-I8 provides up to 256 Mbps incoming bandwidth, while the DS-9632NI-I8 and DS-9664NI-I8 support up to 320 Mbps. This gives larger configurations the network capacity needed to receive video from numerous IP cameras.
16-Channel Synchronous Playback — Review Multiple Cameras Together
When an event involves more than one area, checking cameras individually can make understanding what happened more difficult. With up to 16-channel synchronous playback, you can review multiple recorded views together and follow an event across different camera locations.
4K HDMI Output — See Your Surveillance System on a High-Resolution Display
HDMI 1 supports up to 4K 3840 × 2160 output at 60 Hz, giving you a high-resolution monitoring option for control rooms, security desks, and other installations using compatible 4K displays.
Independent Main and Auxiliary Outputs — Give Operators More Viewing Flexibility
The recorder provides two HDMI and two VGA interfaces. HDMI 1 and VGA 1 operate as the main output, while HDMI 2 and VGA 2 operate as an auxiliary output, making multi-display surveillance configurations easier to organize.
VCA & Smart Camera Functions — Get More Value From Compatible Cameras
The NVR supports multiple Video Content Analytics events and configurable functions from compatible cameras, including motion detection, line crossing, intrusion detection, heat maps, ANPR, and people counting. Instead of relying only on basic recording, your system can make better use of compatible intelligent camera capabilities.
POS Integration — Connect Transactions With Video
For compatible retail applications, POS information can be overlaid on live view and recorded playback. The recorder also supports POS-triggered recording and alarms, helping operators connect transaction information with the corresponding surveillance footage.
Dual Gigabit Ethernet Interfaces — More Flexible Network Management
Two self-adaptive 10/100/1000 Mbps Ethernet interfaces provide additional networking flexibility, with support for Net Fault-Tolerance and Multi-address network modes.
Hik-Connect & Web Access — Manage the System Beyond the Recorder
Support for Hik-Connect, DDNS, and web access without a plug-in gives authorized users additional ways to access and manage the surveillance system over the network.
Stream-Over-TLS Encryption — Add Security to Video Transmission
The recorder supports stream-over-TLS encryption technology for more secure stream transmission, an important consideration when surveillance video is being accessed across a network.
Double Verification — Add More Control to Recorded Evidence Access
Double verification is supported for playback and downloading, providing another layer of control when recorded surveillance footage is being reviewed or exported.
What This Helps You Avoid
Imagine investing in dozens of high-resolution cameras only to discover later that the recorder has become the weakest part of the system. Storage fills faster than expected, adding cameras becomes difficult, reviewing multiple viewpoints takes longer, or the recording platform simply doesn't offer the storage configuration the installation now requires.
Those limitations may not seem important when a system is first installed. But when something actually happens and you need the footage, suddenly recording capacity, playback flexibility, storage reliability, and system performance become much more important.
The DS-9600NI-I8 Series is designed around those larger-system requirements. Eight drive bays, RAID options, hot-swappable storage, H.265+ compression, high-resolution recording, high network bandwidth, 16-channel synchronous playback, and multiple video outputs give you a recorder designed to support a more serious surveillance environment.
The result is a system built not simply to connect cameras, but to give you a stronger foundation for storing, reviewing, and managing the video those cameras produce.
Product Support & Shipping Details
Product Support & Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
For Support you’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Downloads
Product Manuals, data sheets.
Downloads
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Technical Specifications
Hikvision DS-9600NI-I8 Series Professional Network Video Recorder
The Hikvision DS-9600NI-I8 Series is a professional-grade NVR platform designed for larger IP surveillance systems that require high camera capacity, substantial storage, high-resolution recording, and advanced system reliability.
Available in 16-channel, 32-channel, and 64-channel configurations, the series supports IP cameras at resolutions up to 32 MP, 8 internal SATA hard drives, hot-swappable storage, multiple RAID configurations, and independent HDMI and VGA video outputs.
With H.265+ compression, up to 16-channel synchronous playback, dual Gigabit Ethernet interfaces, advanced VCA capabilities, POS integration, and support for Hik-Connect, the DS-9600NI-I8 Series is built for demanding surveillance environments requiring centralized recording and management.
Key Features
- Available with 16, 32, or 64 IP camera channels
- Supports IP camera resolutions up to 32 MP
- H.265+, H.265, H.264+, H.264, and MPEG4 video decoding
- Up to 1-ch @ 32 MP decoding
- Up to 2-ch @ 12 MP decoding
- Up to 4-ch @ 8 MP decoding
- Up to 8-ch @ 4 MP decoding
- Up to 16-ch @ 1080p decoding
- 16-channel synchronous playback
- 8 SATA interfaces with hot-plug support
- Supports up to 10 TB per internal hard drive
- RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10 support
- 1 eSATA interface for additional HDD connectivity
- H.265+ compression can reduce storage requirements by up to 75%
- Dual-stream recording support
- Stream-over-TLS encryption technology
- Double verification support for playback and downloading
- Independent HDMI and VGA video outputs
- HDMI 1 output supports resolutions up to 4K at 60 Hz
- Multiple VCA event support
- Supports compatible camera functions including motion detection, line crossing, intrusion detection, heat map, ANPR, and people counting
- POS information overlay on live view and playback
- POS-triggered recording and alarm support
- 2 self-adaptive 10/100/1000 Mbps Ethernet interfaces
- Supports Hik-Connect and DDNS
- Smooth streaming technology
- Web access without plug-in
- Up to 128 remote connections
- 16 alarm inputs and 4 alarm outputs
Models
Video & Audio
Video Outputs
Decoding & Recording
Storage & RAID
Network
Smart & POS Functions
Security & Reliability
Auxiliary Interfaces
Physical Interfaces
General
Certifications
Accessories
Ideal Applications & Common Uses
The manufacturer datasheet does not provide a specific application list. Based strictly on the capacities and functions documented in the datasheet, the series is suited to surveillance installations requiring a high number of IP cameras, large local storage capacity, RAID storage protection, and centralized video management.
- 16-, 32-, or 64-camera IP surveillance systems
- Systems using high-resolution cameras up to 32 MP
- Installations requiring multiple internal surveillance hard drives
- Applications requiring RAID 0, 1, 5, 6, or 10 storage configurations
- Systems requiring hot-swappable hard drives
- Multi-monitor surveillance environments using independent HDMI/VGA outputs
- Systems using VCA analytics such as intrusion or line-crossing detection
- Compatible ANPR and people-counting surveillance installations
- POS-integrated video surveillance systems
- Systems requiring remote viewing and management through Hik-Connect or web access
Downloads
Frequently Asked Questions
The number of supported IP cameras depends on the model. The DS-9616NI-I8 supports up to 16 channels, the DS-9632NI-I8 supports up to 32 channels, and the DS-9664NI-I8 supports up to 64 channels.
The NVR supports IP camera resolutions up to 32 MP. When Ultra HD resolution mode is enabled, it supports up to 4 channels of 32 MP or 24 MP IP video inputs.
The NVR provides 8 SATA interfaces for internal hard drives, with support for up to 10 TB capacity per disk. It also includes 1 eSATA interface for additional HDD connectivity.
Yes. The NVR supports RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10. Its SATA interfaces support hot-plug operation, allowing supported hard drives to be hot-swapped. The datasheet specifies at least 4 TB for each HDD when using RAID.
Yes. The DS-9600NI-I8 Series supports H.265+, H.265, H.264+, H.264, and MPEG4 decoding. According to the datasheet, H.265+ compression can reduce required storage space by up to 75%.
Yes. HDMI 1 supports video output at up to 4K (3840 × 2160) resolution at 60 Hz or 30 Hz. The NVR also provides a second HDMI output and two VGA outputs for additional display configurations.
The NVR supports up to 16-channel synchronous playback. Its decoding capability includes 1 channel at 32 MP at 30 fps, 2 channels at 12 MP at 20 fps, 4 channels at 8 MP at 25 fps, 8 channels at 4 MP at 30 fps, or 16 channels at 1080p at 30 fps.
Yes. The datasheet lists Hik-Connect and DDNS for network management, supports web access without a plug-in, and allows up to 128 remote connections.
The NVR supports multiple VCA events and configurable smart functions from compatible cameras, including motion detection, line crossing detection, intrusion detection, heat map, ANPR, and people counting. It also supports POS information overlay on live view and playback, as well as POS-triggered recording and alarms.
The DS-9616NI-I8 supports up to 256 Mbps incoming bandwidth, while the DS-9632NI-I8 and DS-9664NI-I8 support up to 320 Mbps incoming bandwidth. Outgoing bandwidth is up to 256 Mbps. When operating in RAID mode, the datasheet specifies up to 200 Mbps incoming and 200 Mbps outgoing bandwidth.
