IDS-7332HQHI-M4/S Hikvision 32ch IP PoE Recorder w/ HDD 1080p 1.5U H.265
IDS-7332HQHI-M4/S Hikvision 32ch IP PoE Recorder w/ HDD 1080p 1.5U H.265
Audio Over Coaxial (AoC)
Human and Vehicle Detection
One Way Audio
Out of stock
Description
Description
Hikvision iDS-7332HUHI-M4/S 32-Channel AcuSense DVR
When you are managing a larger surveillance system, the real challenge is not simply recording more cameras—it is finding important events quickly without being buried in unnecessary alerts. The Hikvision iDS-7332HUHI-M4/S combines 32 analog channels, expandable IP camera support, AcuSense human and vehicle classification, and high-capacity storage options in one professional recorder.
Its hybrid architecture also gives you the flexibility to keep existing coax cameras while adding newer IP cameras as your system grows. Instead of replacing an entire surveillance infrastructure just to gain smarter capabilities, this DVR gives larger systems a practical path toward more intelligent monitoring.
Why Buyers Choose This Model
If your security system covers dozens of cameras, how much time could be lost reviewing motion caused by trees, lights, or other irrelevant activity? This model is built around reducing that friction while giving larger installations the camera capacity, storage flexibility, networking, and video outputs needed for centralized surveillance.
AcuSense Motion Detection 2.0 — Spend Less Time Chasing False Alerts
Deep learning-based Motion Detection 2.0 is enabled by default across all analog channels and can distinguish humans and vehicles from irrelevant motion such as leaves and changing lights. That means operators can focus their attention on activity that is more likely to matter instead of constantly sorting through unnecessary motion events.
Quick Human & Vehicle Search — Find Important Events Faster
The recorder supports quick searching by object or event type. When an incident happens, that can make reviewing footage far more practical than manually scrubbing through hours of recordings looking for the right moment.
Up to 16-Channel Perimeter Protection — Add Intelligence Where It Matters Most
Human and vehicle perimeter analysis is available on up to 16 designated channels. This gives larger properties the ability to apply intelligent filtering to important entrances, parking areas, perimeter zones, loading areas, or other priority camera locations.
32 Analog Channels — Manage Large Camera Systems From One Recorder
With 32 analog video inputs, the iDS-7332HUHI-M4/S is designed for installations where a smaller DVR would quickly become limiting. Instead of dividing a large analog camera system across several small recorders, you can centralize substantially more of the surveillance system in one unit.
Up to 64 Network Camera Inputs — Give Your System Room to Grow
The DVR supports 32 IP channels with expansion up to 64 network camera inputs and IP camera resolutions up to 12MP. If your surveillance requirements expand later, this provides significantly more flexibility than being locked into the original analog camera count.
Hybrid Camera Compatibility — Upgrade Without Starting Over
Support for HDTVI, AHD, HDCVI, CVBS, and IP video gives you considerably more flexibility when dealing with existing surveillance infrastructure. For properties that already have coaxial cameras installed, this can provide a practical way to preserve useful equipment while gradually introducing newer cameras where upgrades make sense.
Up to 8MP Encoding — Preserve More Useful Video Detail
The recorder supports encoding resolutions up to 8MP, including 8MP at 8 fps, 5MP at 12 fps, 4MP at 15 fps, and 3MP at 18 fps. Higher-resolution camera support can provide more recorded detail when identifying activity or reviewing an incident is important.
H.265 Pro+ Compression — Make Better Use of Your Storage
Hikvision's H.265 Pro+ compression is designed to improve encoding efficiency and reduce video storage requirements. For a system recording dozens of cameras, greater compression efficiency can become especially valuable because storage demands multiply quickly as camera count and resolution increase.
Four SATA Bays — Build Storage Around Your Retention Needs
Four SATA interfaces support drives with capacities up to 12TB each, giving you substantial flexibility when configuring surveillance storage. Instead of being restricted by a single-drive recorder, you can build a storage configuration better suited to a larger camera system.
RAID Support — More Options for Managing Critical Video Storage
Support for RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10 gives professional installations multiple ways to configure storage according to performance, capacity, and redundancy requirements.
eSATA Expansion — More Storage Flexibility
In addition to its four internal SATA interfaces, the recorder includes eSATA support. That provides another storage connectivity option when the needs of a larger surveillance deployment go beyond a basic DVR configuration.
Dual Gigabit Ethernet — Built for Heavier Surveillance Networks
Two self-adaptive 10/100/1000 Mbps Ethernet interfaces, 320 Mbps incoming bandwidth, and 256 Mbps outgoing bandwidth give the recorder the networking resources expected from a high-channel-count surveillance system.
Hik-Connect Support — Access and Manage the System Remotely
Hik-Connect and DDNS support provide options for remote network management, while the recorder supports up to 128 remote connections. For businesses or properties where authorized users need access beyond the recorder itself, this provides greater flexibility in how the surveillance system is managed.
4K HDMI Output — View Your System on High-Resolution Displays
HDMI 2 supports output up to 3840 × 2160 at 30Hz, while HDMI 1, VGA, and independent output configurations provide additional display flexibility. This is particularly useful for security desks and monitoring stations where operators may need different camera views across multiple displays.
16-Channel Synchronous Playback — Review Multiple Cameras Together
When an incident moves across several cameras, reviewing only one channel at a time can make it harder to understand what happened. The recorder supports synchronous playback of up to 16 channels, helping operators compare activity across several camera views during the same period.
POS-Triggered Recording & Overlay — Connect Transactions With Video
POS-triggered recording and POS information overlay can make the recorder particularly useful in compatible retail environments. Bringing transaction information and surveillance footage together can help make reviewing activity around a point-of-sale location more efficient.
Alarm & Audio Connectivity — Integrate More Than Video
The recorder includes 16 alarm inputs, four alarm outputs, four RCA audio inputs, an audio output, and independent two-way audio connectivity. These interfaces provide additional options for building a more complete surveillance installation around the recorder.
What This Helps You Avoid
Imagine managing a 20-, 30-, or 40-camera property and receiving motion events every time leaves move, headlights pass, or lighting conditions change. Then imagine an actual incident occurs and someone has to search through hours of footage while trying to determine which cameras captured the person or vehicle involved.
Human and vehicle classification helps filter irrelevant motion, object and event searching helps narrow down investigations, and synchronous playback lets you compare multiple camera views when an event moves across the property.
You also avoid unnecessarily boxing yourself into one camera technology. Because the iDS-7332HUHI-M4/S supports HDTVI, AHD, HDCVI, CVBS, and IP video, an existing analog installation can continue operating while newer IP cameras are introduced as requirements change.
As camera counts increase, storage becomes just as important as recording. Four SATA interfaces, support for up to 12TB per disk, eSATA connectivity, and multiple RAID configurations give you more control over how that footage is stored instead of discovering after installation that your recorder was designed for a much smaller system.
A Smarter Foundation for Larger Surveillance Systems
The iDS-7332HUHI-M4/S makes sense when you need more than a basic DVR. Its combination of 32 analog inputs, expandable IP camera support, AcuSense analytics, large storage capacity, RAID options, dual Gigabit networking, and professional display connectivity creates a platform designed for larger surveillance environments.
Product Support & Shipping Details
Product Support & Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
For Support you’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Downloads
Product Manuals, data sheets.
Downloads
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Technical Specifications
Hikvision iDS-7332HUHI-M4/S 32-Channel 5MP 1.5U H.265 AcuSense DVR
The Hikvision iDS-7332HUHI-M4/S is a high-capacity 32-channel AcuSense DVR designed for surveillance systems that need extensive camera coverage, intelligent human and vehicle detection, and flexible hybrid camera support.
It supports up to 32 analog camera inputs, can accommodate up to 64 network camera inputs, and provides deep learning-based Motion Detection 2.0 across all analog channels to help reduce false alarms caused by objects such as leaves and changing lights.
With support for HDTVI, AHD, HDCVI, CVBS and IP cameras, four SATA interfaces, eSATA expansion, RAID storage options, dual Gigabit Ethernet interfaces and H.265 Pro+ compression, this recorder is built for larger surveillance installations requiring centralized recording, storage and management.
Key Features
- 32-channel 5MP 1.5U AcuSense DVR.
- Deep learning-based perimeter protection.
- Deep learning-based Motion Detection 2.0 for all analog channels.
- Human and vehicle classification to help reduce false alarms.
- Quick search by object or event type.
- Up to 32 analog camera inputs.
- Up to 64 network camera inputs.
- Supports network cameras up to 12MP resolution.
- Supports HDTVI, AHD, HDCVI, CVBS and IP video inputs.
- H.265 Pro+, H.265 Pro, H.265, H.264+ and H.264 video compression.
- Up to 8MP @ 8 fps and 5MP @ 12 fps encoding capability.
- Full-channel recording at up to 4MP Lite resolution.
- 32-channel 1080p @ 30 fps decoding capability.
- Four SATA interfaces plus one eSATA interface.
- Supports up to 12TB per installed disk.
- RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10 storage schemes.
- Two self-adaptive 10/100/1000 Mbps Ethernet interfaces.
- Hik-Connect and DDNS support for network management.
- POS-triggered recording and POS information overlay.
- 16-channel synchronous playback.
- HDMI output including up to 4K resolution through HDMI 2.
- 16 alarm inputs and 4 alarm outputs.
Motion Detection 2.0
Perimeter Protection
Video and Audio
Recording
Network
Storage and Auxiliary Interfaces
General
Physical Interfaces
Available Model
Accessories
Ideal Applications & Common Uses
The datasheet does not provide an official application list. Based on the recorder's stated channel capacity, storage capabilities, hybrid camera compatibility and AcuSense analytics, suitable applications may include:
- Large commercial surveillance systems requiring many camera channels.
- Warehouses and distribution facilities.
- Retail stores and multi-camera retail environments.
- Office buildings and corporate facilities.
- Schools and other large facilities.
- Multi-building or multi-area security deployments.
- Upgrading existing coaxial CCTV installations while retaining analog cabling.
- Hybrid analog and IP surveillance systems.
- Sites that benefit from human and vehicle event filtering.
- Installations requiring RAID-supported surveillance storage.
- POS-integrated surveillance applications.
- Centralized monitoring systems requiring dual-network connectivity and multiple display outputs.
Downloads
Frequently Asked Questions
The iDS-7332HUHI-M4/S provides 32 analog video inputs and supports up to 64 network camera inputs. IP cameras with resolutions up to 12MP are supported.
The DVR supports HDTVI, AHD, HDCVI, CVBS and IP video inputs. Its IP camera support includes H.265+, H.265, H.264+ and H.264 cameras, making it suitable for hybrid surveillance systems using multiple video technologies.
Yes. Deep learning-based Motion Detection 2.0 is enabled by default for all analog channels and can classify humans and vehicles to help reduce false alarms caused by objects such as leaves and lights. The DVR also supports quick searches by object or event type.
Deep learning-based human and vehicle perimeter analysis is supported on up to 16 channels. The supported channels are 1, 2, 3, 4, 9, 10, 11, 12, 17, 18, 19, 20, 25, 26, 27 and 28.
The DVR supports encoding resolutions including 8MP, 3K, 5MP, 4MP, 3MP, 1080p and 720p. Main-stream recording supports 8MP at 8 fps, 3K at 12 fps, 5MP at 12 fps, 4MP at 15 fps and 3MP at 18 fps. Lower resolutions including 1080p and 720p can operate at up to 25 fps in PAL or 30 fps in NTSC.
The recorder has four SATA interfaces and supports up to 12TB capacity for each disk. It also includes eSATA support for additional storage connectivity.
Yes. The DVR supports RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10 storage schemes, providing multiple options for configuring surveillance storage.
Yes. The DVR supports Hik-Connect and DDNS for network management and supports up to 128 remote connections. Supported network protocols include TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF and SNMP.
Yes. HDMI 2 supports display resolutions up to 4K at 3840 × 2160/30Hz. The recorder also provides HDMI 1 and VGA outputs, with HDMI1/VGA simultaneous output and HDMI2/VGA independent output supported.
Yes. The DVR provides four RCA audio inputs, one RCA audio output and one independent RCA connection for two-way audio. It also supports synchronous playback of up to 16 channels.
